Features
- Double weave construction
- Icreased pulling strength
- Protective shoulders to prevent abrasion
- Flexible eye easy match with line swivel
Metric
Short Length - Galvanised Steel
| Slingco Part No. | Range (mm) | Lattice Length (mm) | Approx. Break Load (kg) |
|---|---|---|---|
| ZCS2511 | 13 - 16 | 534 | 2,040 |
| ZCS2512 | 16 - 19 | 610 | 2,540 |
| ZCS2513 | 19 - 25 | 610 | 3,085 |
| ZCS2514 | 25 - 38 | 610 | 4,355 |
| ZCS2515 | 38 - 50 | 610 | 7,441 |
| ZCS2516 | 50 - 63 | 610 | 8,390 |
| ZCS2517 | 63 - 76 | 610 | 11,115 |
| ZCS2518 | 76 - 89 | 610 | 11,115 |
| ZCS2519 | 89 - 102 | 660 | 14,065 |
Longer Length - Galvanised Steel
| Slingco Part No. | Range (mm) | Lattice Length (mm) | Approx. Break Load (kg) |
|---|---|---|---|
| ZCS2520 | 19 - 25 | 914 | 3,085 |
| ZCS2521 | 25 - 38 | 914 | 4,355 |
| ZCS2522 | 38 - 50 | 914 | 7,440 |
| ZCS2523 | 50 - 63 | 914 | 8,390 |
| ZCS2524 | 63 - 76 | 914 | 11,115 |
| ZCS2777 | 76 - 89 | 914 | 11,115 |
| ZCS2778 | 89 - 102 | 1,010 | 14,065 |
Imperial
Short Length - Galvanised Steel
| Slingco Part No. | Range (in) | Lattice Length (in) | Approx. Break Load (lb) |
|---|---|---|---|
| ZCS2511 | 0.50 - 0.62 | 21 | 4,500 |
| ZCS2512 | 0.62 - 0.75 | 24 | 5,600 |
| ZCS2513 | 0.75 - 1.00 | 24 | 6,800 |
| ZCS2514 | 1.00 - 1.50 | 24 | 9,600 |
| ZCS2515 | 1.50 - 2.00 | 24 | 16,400 |
| ZCS2516 | 2.00 - 2.50 | 24 | 18,500 |
| ZCS2517 | 2.50 - 3.00 | 24 | 24,500 |
| ZCS2518 | 3.00 - 3.50 | 24 | 24,500 |
| ZCS2519 | 3.50 - 4.00 | 26 | 31,000 |
Longer Length - Galvanised Steel
| Slingco Part No. | Range (in) | Lattice Length (in) | Approx. Break Load (lb) |
|---|---|---|---|
| ZCS2520 | 0.75 - 1.00 | 36 | 6,800 |
| ZCS2521 | 1.00 - 1.50 | 36 | 9,600 |
| ZCS2522 | 1.50 - 2.00 | 36 | 16,400 |
| ZCS2523 | 2.00 - 2.50 | 36 | 18,500 |
| ZCS2524 | 2.50 - 3.00 | 36 | 24,500 |
| ZCS2777 | 3.00 - 3.50 | 36 | 24,500 |
| ZCS2778 | 3.50 - 4.00 | 40 | 31,000 |
