Features
- Made from 304 stainless steel
- Supports cable in vertical or horizontal mode
- Use when the end of the cable is not accessible
Metric
| Slingco Part No. | Approx. Break Load (kg) | Lattice Length (mm) | Range (mm) |
|---|---|---|---|
| ZCS3031 | 225 | 178 | 12 - 16 |
| ZCS3032 | 340 | 229 | 16 - 19 |
| ZCS3033 | 430 | 254 | 19 - 25 |
| ZCS3034 | 680 | 305 | 25 - 31 |
| ZCS3035 | 680 | 359 | 31 - 38 |
| ZCS3036 | 680 | 381 | 38 - 44 |
| ZCS3037 | 905 | 406 | 44 - 50 |
| ZCS3038 | 1,406 | 483 | 50 - 63 |
| ZCS3039 | 1,406 | 508 | 63 - 76 |
| ZCS3040 | 1,720 | 533 | 76 - 89 |
| ZCS3041 | 1,720 | 533 | 89 - 102 |
Imperial
| Slingco Part No. | Approx. Break Load (lb) | Lattice Length (in) | Range (in) |
|---|---|---|---|
| ZCS3031 | 500 | 7 | 0.50 - 0.63 |
| ZCS3032 | 750 | 9 | 0.63 - 0.75 |
| ZCS3033 | 950 | 10 | 0.75 - 1.00 |
| ZCS3034 | 1,500 | 12 | 1.00 - 1.25 |
| ZCS3035 | 1,500 | 14 | 1.25 - 1.50 |
| ZCS3036 | 1,500 | 15 | 1.50 - 1.75 |
| ZCS3037 | 2,000 | 16 | 1.75 - 2.00 |
| ZCS3038 | 3,100 | 19 | 2.00 - 2.50 |
| ZCS3039 | 3,100 | 20 | 2.50 - 3.00 |
| ZCS3040 | 4,300 | 21 | 3.00 - 3.50 |
| ZCS3041 | 4,300 | 21 | 3.50 - 4.00 |
