Features
- Made from 304 stainless steel
- Supports cable in vertical or horizontal mode
Metric
| Slingco Part No. | Approx. Break Load (kg) | Lattice Length (mm) | Range (mm) |
|---|---|---|---|
| ZCS1915 | 230 | 247 | 12 - 16 |
| ZCS1916 | 335 | 247 | 16 - 19 |
| ZCS1917 | 450 | 331 | 19 - 25 |
| ZCS1918 | 695 | 344 | 25 - 31 |
| ZCS1919 | 695 | 382 | 31 - 38 |
| ZCS1920 | 910 | 420 | 38 - 44 |
| ZCS1921 | 910 | 509 | 44 - 50 |
| ZCS1922 | 1,465 | 535 | 50 - 63 |
| ZCS1923 | 1,815 | 611 | 63 - 76 |
| ZCS1924 | 1,815 | 662 | 76 - 89 |
| ZCS1925 | 1,815 | 738 | 89 - 102 |
| ZCS6408 | 1,815 | 711 | 102 - 114 |
| ZCS6409 | 1,815 | 711 | 114 - 127 |
| ZCS6410 | 1,815 | 711 | 127 - 140 |
Imperial
| Slingco Part No. | Approx. Break Load (lb) | Lattice Length (in) | Range (in) |
|---|---|---|---|
| ZCS1915 | 512 | 9.7 | 0.50 - 0.63 |
| ZCS1916 | 740 | 9.7 | 0.63 - 0.75 |
| ZCS1917 | 1,000 | 13 | 0.75 - 1.00 |
| ZCS1918 | 1,540 | 13.5 | 1.00 - 1.25 |
| ZCS1919 | 1,540 | 15 | 1.25 - 1.50 |
| ZCS1920 | 2,010 | 16.5 | 1.50 - 1.75 |
| ZCS1921 | 2,010 | 20 | 1.75 - 2.00 |
| ZCS1922 | 3,230 | 21 | 2.00 - 2.50 |
| ZCS1923 | 4,000 | 24 | 2.50 - 3.00 |
| ZCS1924 | 4,000 | 26 | 3.00 - 3.50 |
| ZCS1925 | 4,000 | 29 | 3.50 - 4.00 |
| ZCS6408 | 4,000 | 28 | 4.00 - 4.50 |
| ZCS6409 | 4,000 | 28 | 4.50 - 5.00 |
| ZCS6410 | 4,000 | 28 | 5.00 - 5.50 |
