Features
- Double weave lattice
- Stainless steel
- Used in outdoor riser pole applications
Metric
| Slingco Part No. | Range (mm) | Lattice Weave | Lattice Length (mm) | Approx. Break Load (kg) |
|---|---|---|---|---|
| ZCS5430 | 57 - 70 | Double | 533 | 910 |
| ZCS5268 | 82 - 95 | Double | 533 | 2,902 |
| ZCS5062 | 89 - 108 | Double | 533 | 2,902 |
| ZCS4301 | 102 - 114 | Double | 533 | 2,678 |
Imperial
| Slingco Part No. | Range (in) | Lattice Weave | Lattice Length (in) | Approx. Break Load (lb) |
|---|---|---|---|---|
| ZCS5430 | 2.25 - 2.75 | Double | 21 | 2,000 |
| ZCS5268 | 3.25 - 3.75 | Double | 21 | 6,500 |
| ZCS5062 | 3.50 - 4.25 | Double | 21 | 6,500 |
| ZCS4301 | 4.0 - 4.50 | Double | 21 | 6,000 |
