Features
- Made from stainless steel wire
- Designed for heavier cables
- Can support multiple cables in a bundle
- Used when the ends of the cable(s) are not accessible
Metric
| Slingco Part No. | Range (mm) | Lattice Length (mm) | Lattice Material | Approx. Break Load (kg) |
|---|---|---|---|---|
| ZCS7098 | 13 - 16 | 277 | Stainless Steel | 621 |
| ZCS7099 | 16 - 19 | 309 | Stainless Steel | 944 |
| ZCS7100 | 19 - 25 | 351 | Stainless Steel | 944 |
| ZCS7101 | 25 - 32 | 391 | Stainless Steel | 1,211 |
| ZCS7102 | 32 - 38 | 417 | Stainless Steel | 2,037 |
| ZCS7103 | 38 - 44 | 494 | Stainless Steel | 2,037 |
| ZCS7104 | 44 - 51 | 537 | Stainless Steel | 2,269 |
| ZCS7105 | 51 - 63 | 654 | Stainless Steel | 4,056 |
| ZCS7106 | 63 - 76 | 623 | Stainless Steel | 4,056 |
| ZCS7107 | 76 - 87 | 693 | Stainless Steel | 6,089 |
| ZCS7108 | 87 - 102 | 914 | Stainless Steel | 6,089 |
Imperial
| Slingco Part No. | Range (in) | Lattice Length (in) | Lattice Material | Approx. Break Load (lb) |
|---|---|---|---|---|
| ZCS7098 | 0.50 - 0.63 | 11 | 304 SS | 1,370 |
| ZCS7099 | 0.63 - 0.75 | 12 | 304 SS | 2,080 |
| ZCS7100 | 0.75 - 1.00 | 14 | 304 SS | 2,080 |
| ZCS7101 | 1.00 - 1.25 | 15 | 304 SS | 2,670 |
| ZCS7102 | 1.25 - 1.50 | 16 | 304 SS | 4,490 |
| ZCS7103 | 1.50 - 1.75 | 16.5 | 304 SS | 4,490 |
| ZCS7104 | 1.75 - 2.00 | 17.5 | 304 SS | 5,000 |
| ZCS7105 | 2.00 - 2.50 | 26 | 304 SS | 8,940 |
| ZCS7106 | 2.50 - 3.00 | 25 | 304 SS | 8,940 |
| ZCS7107 | 3.00 - 3.50 | 27 | 304 SS | 13,420 |
| ZCS7108 | 3.50 - 4.00 | 36 | 304 SS | 13,420 |
