Features
- Made from stainless steel wire
- Designed for heavier cables
- Can support multiple cables in a bundle
- Used when the ends of the cable(s) are not accessible
Metric
| Slingco Part No. | Range (mm) | Lattice Length (mm) | Lattice Material | Approx. Break Load (kg) |
|---|---|---|---|---|
| ZCS7087 | 13 - 16 | 277 | Stainless Steel | 621 |
| ZCS7088 | 16 - 19 | 309 | Stainless Steel | 944 |
| ZCS7089 | 19 - 25 | 332 | Stainless Steel | 944 |
| ZCS7090 | 25 - 32 | 391 | Stainless Steel | 1,211 |
| ZCS7091 | 32 - 38 | 417 | Stainless Steel | 2,037 |
| ZCS7092 | 38 - 44 | 589 | Stainless Steel | 2,037 |
| ZCS7093 | 44 - 51 | 569 | Stainless Steel | 2,269 |
| ZCS7094 | 51 - 63 | 654 | Stainless Steel | 4,056 |
| ZCS7095 | 63 - 76 | 623 | Stainless Steel | 4,056 |
| ZCS7096 | 76 - 87 | 749 | Stainless Steel | 6,089 |
| ZCS7097 | 87 - 102 | 950 | Stainless Steel | 6,089 |
Imperial
| Slingco Part No. | Range (in) | Lattice Length (in) | Lattice Material | Approx. Break Load (lb) |
|---|---|---|---|---|
| ZCS7087 | 0.50 - 0.63 | 11 | 316 SS | 1,370 |
| ZCS7088 | 0.63 - 0.75 | 12 | 316 SS | 2,080 |
| ZCS7089 | 0.75 - 1.00 | 13 | 316 SS | 2,080 |
| ZCS7090 | 1.00 - 1.25 | 15.5 | 316 SS | 2,670 |
| ZCS7091 | 1.25 - 1.50 | 16.5 | 316 SS | 4,490 |
| ZCS7092 | 1.50 - 1.75 | 23 | 316 SS | 4,490 |
| ZCS7093 | 1.75 - 2.00 | 22 | 316 SS | 5,000 |
| ZCS7094 | 2.00 - 2.50 | 26 | 316 SS | 8,940 |
| ZCS7095 | 2.50 - 3.00 | 24.5 | 316 SS | 8,940 |
| ZCS7096 | 3.00 - 3.50 | 29.5 | 316 SS | 13,420 |
| ZCS7097 | 3.50 - 4.00 | 37.5 | 316 SS | 13,420 |
