Features
- Easy to install
- Low cost safety solution
- For air hoses up to 200psi (5 to 1 safety factor)
Hose to Hose
| Slingco Part No. | Hose Range in (mm) | Wire Thickness mm | Length in (mm) | Material | Max WP Psi | WLL kN |
|---|---|---|---|---|---|---|
| ZWR14271 | 3/8 - 1 1/4 (10-32) | 3.5 | 22 (550) | Galvanized | 200 | 6.5 |
| ZWR11534 | 1/2 - 1 1/4 (13-32) | 3 | 22 (550) | Galvanized | 200 | 5.7 |
| ZWR11530 | 1/2 - 1 1/4 (13-32) | 3 | 22 (550) | Stainless Steel | 200 | 5.7 |
| ZWR14272 | 1 1/4 - 2 (32 - 50) | 6 | 33 (850) | Galvanized | 200 | 17.6 |
| ZWR11535 | 1 1/2 - 3.0 (38-76) | 6 | 42 (1060) | Galvanized | 200 | 21.2 |
| ZWR14273 | 2 1/2 - 4 (63 - 100) | 6 | 45 (1150) | Galvanized | 200 | 17.6 |
| ZWR14274 | 4 - 6 (100 - 150) | 10 | 45 (1150) | Galvanized | 200 | 49.0 |
