Features
- Lightweight application
- Reduces strain on electrical connections
- Available in Galvanized or Stainless Steel Wire
Metric
| Slingco Part No. | Range (mm) | Wire Material | Eye Length (mm) | Approx. Break Load (kg) |
|---|---|---|---|---|
| ZCS6969 | 6.1 - 8.1 | Galvanised | 88.9 | 158 |
| ZCS6970 | 8.1 - 10.9 | Galvanised | 101.6 | 204 |
| ZCS6971 | 10.9 - 14.2 | Galvanised | 120.6 | 249 |
| ZCS6972 | 14.2 - 18.5 | Galvanised | 152.4 | 453 |
| ZCS6973 | 18.5 - 21.6 | Galvanised | 171.4 | 635 |
| ZCS6974 | 21.6 - 25.4 | Galvanised | 203.2 | 635 |
| ZCS6975 | 25.4 - 31.7 | Galvanised | 241.3 | 680 |
| ZCS09744 | 6.1 - 8.1 | 304 Stainless Steel | 88.9 | 45.36 |
| ZCS09745 | 8.1 - 10.9 | 304 Stainless Steel | 101.6 | 117.9 |
| ZCS09746 | 10.9 - 14.2 | 304 Stainless Steel | 120.6 | 249 |
| ZCS09717 | 14.2 - 18.5 | 304 Stainless Steel | 152.4 | 453 |
| ZCS09747 | 18.5 - 21.6 | 304 Stainless Steel | 171.4 | 635 |
| ZCS09748 | 21.6 - 25.4 | 304 Stainless Steel | 203.2 | 635 |
| ZCS09749 | 25.4 - 31.7 | 304 Stainless Steel | 241.3 | 680 |
| ZCS09968 | 10.9 - 14.2 | ALL 316 Stainless Steel | 120.6 | 249 |
| ZCS09969 | 14.2 - 18.5 | ALL 316 Stainless Steel | 152.4 | 453 |
| ZCS10400 | 18.5 - 21.6 | ALL 316 Stainless Steel | 171.4 | 635 |
| ZCS10401 | 21.6 - 25.4 | ALL 316 Stainless Steel | 203.2 | 635 |
Imperial
| Slingco Part No. | Range (in) | Wire Material | Eye length (in) | Approx. Break Load (lb) |
|---|---|---|---|---|
| ZCS6969 | 0.22 - 0.32 | Galvanized | 3.5 | 350 |
| ZCS6970 | 0.30 - 0.43 | Galvanized | 4 | 450 |
| ZCS6971 | 0.41 - 0.56 | Galvanized | 4.75 | 550 |
| ZCS6972 | 0.53 - 0.73 | Galvanized | 6 | 1,000 |
| ZCS6973 | 0.70 - 0.85 | Galvanized | 6.75 | 1,400 |
| ZCS6974 | 0.82 - 1.00 | Galvanized | 8 | 1,400 |
| ZCS6975 | 0.96 - 1.25 | Galvanized | 9.5 | 1,500 |
| ZCS09744 | 0.22 - 0.32 | 304 Stainless Steel | 3.5 | 100 |
| ZCS09745 | 0.30 - 0.43 | 304 Stainless Steel | 4 | 260 |
| ZCS09746 | 0.41 - 0.56 | 304 Stainless Steel | 4.75 | 550 |
| ZCS09717 | 0.53 - 0.73 | 304 Stainless Steel | 6 | 1,000 |
| ZCS09747 | 0.70 - 0.85 | 304 Stainless Steel | 6.75 | 1,400 |
| ZCS09748 | 0.82 - 1.00 | 304 Stainless Steel | 8.0 | 1,400 |
| ZCS09749 | 0.96 - 1.25 | 304 Stainless Steel | 9.5 | 1,400 |
| ZCS09968 | 0.41 - 0.56 | ALL 316 Stainless Steel | 4.75 | 550 |
| ZCS09969 | 0.53 - 0.73 | ALL 316 Stainless Steel | 6 | 1,000 |
| ZCS10400 | 0.70 - 0.85 | ALL 316 Stainless Steel | 6.75 | 1,400 |
| ZCS10401 | 0.82 - 1.00 | ALL 316 Stainless Steel | 8.0 | 1,400 |
